Shearing And Slitting Lines

CR/HR Slitting Lines

Magadh can offer CR/HR slitting lines for strip width up to 2500 mm, process speed up to 200 MPM for HR slitting and 300 MPM for CR slitting lines for strip thickness of 25.4 mm to 0.12 mm.

The Main features are:

• Conventional/double eccentric design slitter head
• Side shifting/turret type head changing arrangement
• Scrap ballers for high productivity

CR/HR Cut-to-Length Lines

Magadh can offer CR/HR cut-to-length lines for strip width up to 2000 mm, process speed up to 120 MPM for strip thickness of 12.5 mm to 0.12 mm.

The Main features are:

• Rotary shears for precision length control at high speeds
• 17/19 rolls 6 hi multi correction levelers
